Additional information
| Types | Frame |
|---|---|
| Feature | Accessories, New Arrivals |
| Size | 1200*300, 1200*600, 600*600, 620*620 |
| Height | 50mm, 62mm, 65mm, 70mm |
Be the first to review “Surface mounting frame screwless” Cancel reply
RAL9016, easy to assembly, fast installation, edgelit panel light and backlit panel light is available
view the place
| Types | Frame |
|---|---|
| Feature | Accessories, New Arrivals |
| Size | 1200*300, 1200*600, 600*600, 620*620 |
| Height | 50mm, 62mm, 65mm, 70mm |
Specifications
|
Input Voltage : |
AC200V-240V , 50/60Hz |
|
Dimension : |
600x600x34mm |
| LED Chip : | San’an / Philips / Osram option |
|
Norminal Power : |
25W |
|
Luminous Flux (LM) : |
180lm/w |
|
CCT : |
4000K |
|
CRI : |
Ra>80 |
|
Driver : |
Lifud / Philips / Boke / AGT / Osram option |
|
Power Factor : |
PF>0.95 |
|
UGR(Unified Glare Rating) : |
UGR<19 |
|
Materials : |
Aluminum frame , PMMA lens |
|
IP Rating : |
IP40 |
|
Lifetime : |
50000H (L80B20) |
|
Warranty : |
5 years |
|
Working Ambient Temp. : |
-20~+40‚ÑÉ |
|
Working Ambient Humidity : |
10%~90% |
|
Mounting : |
Recessed , Suspending , Surface mounted , Spring clips , T-bar |
|
Dimmable : |
On/Off / Push / Triac / 0-10V / 1-10V / DALI dimming |
|
Certificate : |
ENEC , TUV-GS , UKCA , CE , RoHS , ErP , CB |
